Mini Excavator

^ K CT16-9B MINI EXCAVATOR SPECIFICATIONS

Engine

Ratio Travel

Model

Yanmar 3TNV70

Travel motorum

Eton, USA

Type

Iniectio directa, aqua refrigerata, attractio naturalis

Support cylindro quantitates

2×3

Carrier cylindro quantitates

2×1

No. cylindrici

3

Iter calceamenta

No

Pertundere et plaga

70x74(mm)

Celeritas Travel

2.7/5.0(km/h)

Displacement

0.854L

Drawbar trahens vi

11.7kN

Virtus output

10kw/2200rpm

Gradeability

58%(300)

Maximilianus. torque

50N.m/2000rpm

Terram alvi

160mm

Systema hydraulicum

Cab & Electrical System

Pump

CASAPPA, Italy

Cab

Tempestas omnis, soni-Cab oppressa et instructa gravi, insulato Tabulato Mat, Ante Fenestra aperiri et prolabi potest; Populus Novifacta Sedes

Type

Axial-piston sentinam+ calces pump

Maximilianus. missionem fluxus

2x20+15.1(L/min)

Maximilianus. missionem pressura

Boom, brachium et situla

17 MPa

Voltage

12V

Circuitus Travel

12 MPa

gravida

1X12V

Circuitus adductius

9 MPa

Pugna facultatem

60Ah

Imperium circuit

3 MPa

Boom, Arm & Situla

Gubernator imperium sentinam

genus calces

Boom cylindrici

Φ60xΦ35xS440-L770

Principalis imperium valvulae

Hydro Control, Italy

Brachium cylindricum

Φ60xΦ35xS330-L600

Oleum frigidior Thracam

Genus aeris refrigeratum

Situla cylindrici

Φ55xΦ30xS300-L560

Ratio adductius

Implere capacitatem & lubricationem

adductius motricium

Eton, USA

Fuel tank

28L

Motor genus validam

Axial-piston motricium

Systema refrigerandum

8L

Fregit

No

Engine oleum

4.4L

Quisque fregit

No

Hydraulica oleum cisternina

17.5L Tank Oleum Level

Celeritas adductius

8.8 r/min

24L Ratio hydraulica

Situla

Type

Backhoe situla

Situla facultatem

0.04m3 (SAE)

Situla capacitatis scope

0.028-0.095m3

Numerus situla dentium

3 aut 4

Situla latitudo

450 mm

opus iugis

Boom longitudo

1829m

Brachium longitudinem

950mm

Maximilianus. fodiendi altitudo

3281mm

Maximilianus. dumping altitudo

2393mm

Maximilianus. fodiendo profundum

2033mm

Maximilianus. verticalis fodiendi profundum

1605mm

Maximilianus. fodiendi spatium

3941mm

Maximilianus. fodiendi radium humi campester

3878mm

Min adductius radii operis apparatu

1625mm

Situla vi fodiendi

11.2 KN

Brachium fodiendi vi

9.1 KN

Super Dimensiones

Longitudo altiore

3694mm

Inuestigandum grounding longitudo

1210mm

Terram contactum longitudinem

(Transportation)

2366mm

Semita longitudinem

1588mm

Altitudo altiore (to top of BUTIO)

1157mm

Vestigium gauge (extensio 1090mm)

760mm

Altiore latitudine

1000mm

Semita latitudo (extensio 1320mm)

990mm

Altitudo altiore (to top of cab)

2411 mm

Semita ornare risus

230mm

Contra pondus alvi terra

207mm

Bonnet height

1222mm

Min. Terram alvi

160mm

Revolvens frame latitudine

1000mm

Cauda adductius radii

660mm

Procul ab adductius centrum ad caudam

665mm

Operating Pondus et Terra Pressura

operating pondus

1700kg (cum conopeo)

Terra pressura

XXVIII KP

stipare

Nuda Pack. Commoditatis sarcina secundum regulam exportandi fabricae sarcinam erit, longis spatiis vecturae oceani et mediterranei apta erit. Venditator contra humorem, fruges et aeruginem pro opportunitate commoditatis providebit.

Fabricator ius technicae alterationis/mutationis melioris emendationis sine praevia notatione reservat
